Modbus TCP

Modbus TCP is a connection type for ModbusDevice, not a separate driver class: set "transport": "tcp" in the config’s connection block, or pass a ModbusTCPTransport explicitly.

Creating a `ModbusDevice` over TCP

from instro.modbus import ModbusDevice

# connection block declared inline, e.g. { "transport": "tcp", "host": "192.168.1.100", "port": 502 }
device = ModbusDevice(config="my_device.json")
device.open()

Or with an explicit, shareable transport:

from instro.lib.transports import ModbusTCPTransport
from instro.modbus import ModbusDevice

transport = ModbusTCPTransport(host="192.168.1.100", port=502)
device = ModbusDevice(config="my_device.json", connection=transport, unit_id=1)

Parameters and methods specific to ModbusDevice can be found in the SDK.
